Intensity and Durability : Glass fiber Reinforced Panel is molded under condition of high temperature and pressure to maintain the best endurance. Since using stainless steel for inside structure and HDG steel for outside, it shows best performance against erosion.
The heat insulation panel with 3 layer structured improves heat insulation effect. Protects water from dewdrops and minimizes temperature variation of the stored water.
Water tightnessThe joints are sealed with special sealing tape especially developed for water tank.
Size Stability GRP Sectional water tank panels size are changeless from the outside condition so assemble it accurately.
Various sized panels used limited space for its best using way so can satisfy your needs.
GRP Sectional panels make construction time shorter, standardization panels make easier to moving, carrying in and transfer.
BK reseves the right to provide alternate skid base designs. BK recommedns and ideal concrete plinth size of 400mm(W) x 475mm(H) with maximum variance in height of not more than 2mm
The panels are interconnected with stainless steel tie rods in the GRP water tank to guarantee the strenght of water tank
The joint of the side panel is supported with an external reinforcement frame, the upper part, fixed with angles and oundbar stays, and the lower part. connected and fixed with brackets using bolts(the height of the tank is 3m or less)
